Aluprof MB-70 Thermally Insulated Aluminum System | Windows, Doors, & Shop Fronts | High Security

Name: Aluprof MB-70 Thermally Insulated Aluminum System | Windows, Doors, & Shop Fronts | High Security
Brand: Aluprof
Availability: InStock

$0.00

785 in stock

The Aluprof MB-70 is a versatile aluminum system designed for fabricating various thermal and sound-insulated external structures, including windows, doors, entrance enclosures, shop fronts, and spatial structures.

It features a stable, 3-chamber structure with thermal breaks, ensuring excellent insulation properties.

Versatile Application: Ideal for both new construction and renovation of existing buildings.
Enhanced Thermal Performance: A high-insulation (HI) version is available, utilizing special insulating inserts to further reduce heat transfer.
Security Options: The MB-70 platform is suitable for fabricating burglar-resistant windows and doors up to RC4 class.
Fire Safety: A separate MB-70 fire-rated system is available for fire-resistant windows and smoke exhaust windows.

Pricing Information

Prices for the Aluprof MB-70 system vary significantly based on the configuration, size, glazing package, and finish selected.

Please contact a fabricator or distributor for a specific quote based on your project requirements.

Orders over $800 ship free
30 day returns

Material & Dimensions

Profile Construction and Glazing

Frame Depth: 70 mm.
Sash (Vent) Depth: 79 mm.
Glazing Thickness Range (Frames): Supports glass or panels from 15 mm to 60 mm.
Glazing Thickness Range (Sashes): Supports glass or panels from 24 mm to 70 mm.
Thermal Breaks: Uses specialized thermal breaks that are 34 mm wide.

Performance Ratings

Frame Thermal Insulation (Uf): The heat transfer coefficient for the frame (Uf) ranges from 1.0 W/(m²K) to 2.3 W/(m²K), depending on the specific profile.
Watertightness: Achieves a rating of Class E1050 (1050 Pa).
Air Permeability: Achieves the highest performance rating of Class 4.
Wind Load Resistance: Achieves a high performance rating of Class C5.

Key Features and Available Types

Window Types: The system supports common configurations including fixed, turn, tilt, and tilt-and-turn windows.
Door Types: Supports inward- and outward-opening single and double-leaf doors.
Concealed Sash: Includes specialized versions (MB-70US / MB-70US HI) that feature a concealed sash for a uniform, aesthetically clean glass surface.
Industrial Version: The MB-70 Industrial version is designed specifically for historic buildings and industrial applications.
Facade Integration: The system serves as a base for the MB-70CW / MB-70CW HI window system, allowing for continuous window and door construction.
