Schüco ASS 80 FD.HI Folding Door | High Thermal Insulation | 90° Corner Option | RC2 Security

Name: Schüco ASS 80 FD.HI Folding Door | High Thermal Insulation | 90° Corner Option | RC2 Security
Brand: Schuco
Price: 2150.00 USD
Availability: InStock

$2,150.00

1100 in stock

The Schüco ASS 80 FD.HI (Folding Door High Insulated) system is a highly thermally insulated aluminum folding door that effortlessly opens entire glass walls, ideal for luxury homes and commercial projects.

It achieves excellent energy efficiency through extended insulation zones, a center gasket in the outer frame, and specialized glazing rebate insulation.

Exceptional Versatility: Offers a wide range of types and opening options, including the attractive 90-degree corner solution for fully open, post-free corners.
Thermal Performance: Achieves high insulation values, making it compliant with strict energy requirements like EnEV 2009, and suitable for low-energy and Passive House strategies.
Barrier-Free Access: Features an optional flat, thermally insulated threshold for seamless, barrier-free access between interior and exterior spaces.
Design & Comfort: Includes narrow face widths (from 4.4 inches at the fold) and optional features like a magnetic retaining catch for securing folded panels and a flat handle design.

Pricing Information (US Estimates)

The Schüco ASS 80 FD.HI is a premium German-engineered system, and its high insulation and flexible corner capability place it at a high price point.

Estimated Starting Price: The price of a set of Schüco bifold doors starts at around $2,100 to $2,550 USD per panel (excluding glass, installation, and corner posts).
Cost Context: The high thermal performance and advanced features (like the 90° corner option) mean the final cost per square foot will be significantly higher than standard folding doors.

Orders over $800 ship free
30 day returns

Material & Dimensions

Thermal and Weather Ratings

Basic Frame Depth: 3.15 inches (80 mm).
Overall Door Insulation (Uw): Can achieve Uw values from 0.23 BTU per hr sq ft F (1.3 W per meter squared Kelvin) Schüco ASS 80 FD.HI - Alu Group - Aluminum Building Solutions.
Frame U-Value (Uf): Down to 0.30 BTU per hr sq ft F (1.7 W per meter squared Kelvin) Schüco ASS 80 FD.HI - Alu Group - Aluminum Building Solutions.
Air Permeability: Up to Class 3 (EN 12207).
Watertightness: Up to Class 9A (EN 12208).
Wind Load Resistance: Up to Class C3/B3 (EN 12210).
Burglar Resistance: Up to RC2 class (WK2).

Construction and Capacity

Max Vent Weight: Up to 220 pounds (100 kg) per leaf.
Max Vent Height: Up to 9.84 feet (3000 mm).
Max Vent Width: Up to 3.94 feet (1200 mm) per leaf.
Visible Interlock Mullion: 4.41 inches (112 mm) for a standard fold.
Glazing Thickness Range: Supports glass from 0.51 inches up to 2.24 inches (13 to 57 mm).
Operation: Units can be folded to the right, left, inwards, or outwards as required.
Integration: Can integrate Schüco AWS 70 BS.HI window vents as a turn/tilt window within the folding panel for flexible ventilation Schüco Folding Sliding System ASS 80 FD.HI.
