The Schüco AWS 60 is a versatile standard window system featuring a construction depth of 60 mm (approx. 2.36 inches) and outstanding thermal insulation properties.

This product meets all international requirements for variety and quality, making it a reliable solution for numerous architectural applications.

Versatile Use: The system can be used as facade elements, ribbon windows (horizontal strips of windows), or single-unit punched windows.
Compatibility: Works perfectly in combination with Schüco door systems.
Operation: Available for inward or outward opening, and can be fitted with concealed electromechanical or manual hardware.
Aesthetics: The system offers narrow face widths and supports large glass areas, providing a modern, sleek appearance.

Pricing and Availability Note:

As a project-based component, pricing for the Schüco AWS 60 is highly customized. Costs depend on specific dimensions, hardware type (manual or electromechanical), and the chosen finish (RAL color). Please contact us for a specific project quote.

Orders over $800 ship free
30 day returns

Material & Dimensions

Performance and Ratings

Thermal Insulation (Uf): Standard frame Uf values typically range from 2.0 W per meter squared Kelvin, with options to improve this through glazing.
Air Permeability: Achieves Class 4 (the highest rating, EN 12207).
Watertightness: Achieves Class E 900 (EN 12208).
Wind Load Resistance: Achieves Class C5 / B5 (EN 12210).
Acoustic Insulation (Rw): Up to 43 dB, depending on the glass unit used.

Construction and Dimensions

Construction Depth: 60 mm (frame depth).
Sash Depth: 70 mm.
Glazing Range: Accommodates glass thickness up to 47 mm.
Opening Types: Turn, tilt, tilt-and-turn, bottom-hung, top-hung, and pivot windows.
Security: Compatible with anti-burglary hardware up to RC3 class.

Key Features and Options

Concealed Hardware: Supports the use of concealed or hidden fittings for a minimalist look.
Schüco TipTronic: Can be seamlessly integrated with the Schüco TipTronic electromechanical hardware for automated operation and security monitoring.
Finishes: Available in a wide variety of finishes, including the full RAL color palette and anodized finishes.
System Depth: The 60 mm depth is an optimal solution for numerous standard construction needs.
Accessibility: Supports options for low thresholds or threshold-free transitions for enhanced accessibility.
